Yamaha F100X - Oil Pan Exploded Diagram

7-11
E
BRKT
OIL PAN
OIL PAN
EXPLODED DIAGRAM
1
2
3
4
5
6
7
8
9
10
13
14
15
16
17
18
19
12
11
6 × 25 mm
6 × 25 mm
6 × 70 mm
6 × 50 mm
6 × 30 mm
LT
LT
572
LT
LT
572
LT
LT
572
LT
LT
572
LT
LT
572
10 Nm
(1.0 m
•
kg, 7.2 ft
•
Ib)
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
A
REMOVAL AND INSTALLATION CHART
Step Procedure/Part name Q’ty Service points
OIL PAN DISASSEMBLY Follow the left “Step” for removal.
1 Bolt 6
2 Bolt 1
3 Muffler 1
4 Rubber seal 1
5 Water pipe 1
6 Rubber seal 1
7 Exhaust manifold gasket 2
8 Plate 1
9 Exhaust seal 1
10 Bolt 4
Not reusable
