Yamaha F100X - Page 308

7-2
E
BRKT
SHIFT ACTUATOR ASSY.
EXPLODED DIAGRAM
1
2
4
5
8
9
10
11
12
15
16
17
18 Nm (1.8 m
•
kg, 13 ft
•
Ib)
A
A
14
3
13
15
7
6
6 × 40 mm
6 × 25 mm
Step Procedure/Part name Q’ty Service points
9 Spring 1
10 Ball 1
11 Cotter pin 1
12 Washer 1
13 Bolt 2
14 Shift actuator bracket 1
15 Bushing 2
16 Gear shift handle 1
17 Grommet 1
Reverse the disassembly steps for
installation.
