5-7
EMN34810
Emergency Starting Engine
1) Remove the top cowling.
2) Remove the cable 1 by pulling out it
from the starter if equipped.
E
204053**
w
208066
e
204054
3) Remove both ends of the choke rink
rod 2.
6) Pull up the lever 3 on the carburetor
to operate the choke system when the
engine is cold.
After the engine starts, return the
lever to the original position.
4) Remove the starter/ flywheel cover
after removing 3 bolts.
Disconnect the wire leads connected
the starter/ flywheel cover.
5) Prepare the engine for starting. See
“STARTING ENGINE” for procedures.
Be sure the engine is in Neutral and
that the lanyard lock plate is attached
to the engine stop lanyard switch.
