MAIN COMPONENTS
1 Top cowling
2 Top cowling lock lever
3 Oil drain bolt
4 Anti-cavitation plate
5 Propeller
6 Cooling water inlet
7 Trim angle adjusting rod
8 Clamp bracket
* 9 Recoil starter handle
0 Choke knob
q Warning indicator
* w Gear shift lever
* e Tiller handle
r Steering friction adjusting lever
t Transom clamp handle
y Rope attachment
* u Tilt lock lever
i Flushing device
* o Starter button
* p Power tilt switch
* a Tilt support knob
* s Remote control
* May not be exactly as shown; also may not
be included as standard equipment on all
models.
