Yamaha F300B - Cooling Water Hose

6-4
Hose routing
0
1
2
3
4
5
6
7
8
9
10
A
Cooling water hose
a Cooling water hose (cylinder block to oil
cooler)
b Cooling water hose (cylinder block to fuel
cooler)
c Cooling water pilot hose (fuel cooler to oil
cooler)
d Cooling water hose (oil filter bracket to cyl-
inder block)
e Cooling water hose (oil cooler to oil filter
bracket)
f Cooling water hose (oil cooler to joint)
g Cooling water hose (thermostat cover
[STBD] to joint)
h Cooling water hose (joint to Rectifier Reg-
ulator)
i Cooling water hose (Rectifier Regulator to
joint)
j Cooling water hose (joint to joint)
k Cooling water hose (joint to cooling water
outlet)
l Cooling water hose (flushing hose adapter
to joint)
f
b
h
q
i
l
a
b
a
c
d
b
o
r
ad
e
m
k
j
e
cgf
p
ec a
b
c
n
