– 17 –
BRKT
E
STEERING HANDLE (OPTION)
EXPLODED DIAGRAM
Step Procedure/Part name Q’ty Service points
8 Holder 1
9 Screw 1
10 Throttle grip 1
11 Washer 1
12 Spring 1
13 Bushing 1
14 Screw 5
15 Screw 2
16 Cover 1
17 Screw 2
18 Power trim and tilt switch 1
