Yamaha F80A - Neutral Switch Removal

– 22 –
BRKT
E
STEERING HANDLE (OPTION)
EXPLODED DIAGRAM
REMOVAL AND INSTALLATION CHART
Step Procedure/Part name Q’ty Service points
NEUTRAL SWITCH REMOVAL Follow the left “Step” for removal.
Junction box cover Refer to “STEERING HANDLE
REMOVAL”.
1 Neutral switch lead 2
2 Screw 3
3 CDI unit cover 1
4 Throttle position sensor (TPS)
coupler
1
5 Link rod 1
6 Bolt 2
