Yamaha F80A - Page 54

– 21 –
BRKT
E
STEERING HANDLE (OPTION)
EXPLODED DIAGRAM
Step Procedure/Part name Q’ty Service points
23 Bushing 1
24 Nut 1
25 Washer 1
26 Bolt 1
27 Washer 1
28 Wave washer 1
29 Collar 1
30 Bracket 1
31 Washer 1
32 Bushing 2
33 Steering handle 1
Reverse the disassembly steps for
assembly.
