TIGHTENING TORQUES

2-17

EAS20350

CHASSIS TIGHTENING TORQUES

Item

Thread

size

Q’ty Tightening torque Remarks

Upper bracket pinch bolt M8 2 26 Nm (2.6 m·kg, 19 ft·lb)

Steering stem nut M28 1 113 Nm (11.3 m·kg, 82 ft·lb)

Upper handlebar holder bolt M8 4 24 Nm (2.4 m·kg, 17 ft·lb)

Lower handlebar holder nut M10 2 32 Nm (3.2 m·kg, 23 ft·lb)

Lower bracket pinch bolt M8 4 23 Nm (2.3 m·kg, 17 ft·lb)

Lower ring nut M30 1 SEE NOTE

Cap bolt M46 2 23 Nm (2.3 m·kg, 17 ft·lb)

Damper rod assembly bolt M10 1 23 Nm (2.3 m·kg, 17 ft·lb)

Brake master cylinder bracket bolt M6 2 10 Nm (1.0 m·kg, 7.2 ft·lb)

Brake master cylinder reservoir

cap screw

M4 2 2 Nm (0.2 m·kg, 1.4 ft·lb)

Front brake hose union bolt M10 3 30 Nm (3.0 m·kg, 22 ft·lb)

Front brake hose holder bolt M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)

Cowling stay bolt (FZ1-S(W),

FZ1-SA)

M8 2 33 Nm (3.3 m·kg, 24 ft·lb)

Cowling bracket bolt (FZ1-S(W),

FZ1-SA)

M6 2 7 Nm (0.7 m·kg, 5.1 ft·lb)

Front fender bolt M6 4 6 Nm (0.6 m·kg, 4.3 ft·lb)

Clutch lever holder pinch bolt M6 1 11 Nm (1.1 m·kg, 8.0 ft·lb)

Right front engine mounting bolt 1 M10 1 45 Nm (4.5 m·kg, 33 ft·lb)

Right front engine mounting bolt 2 M10 1 50 Nm (5.0 m·kg, 36 ft·lb)

Left front engine mounting bolt M10 1 45 Nm (4.5 m·kg, 33 ft·lb)

Upper self-locking nut M10 1 51 Nm (5.1 m·kg, 37 ft·lb)

Lower self-locking nut M10 1 51 Nm (5.1 m·kg, 37 ft·lb)

Engine mounting adjust bolt

(upper)

M11 1 7 Nm (0.7 m·kg, 5.1 ft·lb)

Engine mounting adjust bolt

(lower)

M11 1 7 Nm (0.7 m·kg, 5.1 ft·lb)

Pivot shaft nut M18 1 105 Nm (11 m·kg, 76 ft·lb)

Connecting arm nut (connecting

arm and frame)
