MIDI Data Format
Appendix
00...7F Free EG Trk4 Data2 LSB 0...127 *2 0
: : :
0C 66 2 00...01 Free EG Trk4 Data192 MSB 0...1 *2 1
00...7F Free EG Trk4 Data192 LSB 0...127 *2 0
TOTAL SIZE 668
*1 : see other table (Free EG Track Paramter List)
*2 : only Bulk Dump (not received as parameter change)
*3 : BPM = ((1st & 03h) * 128 + 2nd) + ((1st & 78h)/8)/10
<1-3>
MIDI Parameter Change table ( Current Voice Element Buffer )
Address Size Data Prameter Name Description Default
(H) (H) (H)
10 10 00 1 00...02 Key Assign Mode poly(0),mono(1),legato(2) 00(poly)
01 1 28...58 Pich Up (PB Range +) -24(28)...+24(58) 42(+2)
02 1 28...58 Pich Down (PB Range -) -24(28)...+24(58) 3E(-2)
03 1 00...7F PEG Decay 0...127 0
04 1 00...7F PEG Depth -64...+63 semitones 40(+0)
05 1 01...03 PEG Switch VCO1(1),VCO2(2),both(3) 03(both)
06 1 00...01 Portamento Mode normal(0),sustain-key(1) *1 00(normal)
full-time(0),fingered(1) *2
07 1 00...7F Portamento Time 0...127 2C(44)
08 1 00...01 LFO Reset Mode off(0),key-on(1) 00(off)
09 1 00...14 LFO1 Wave sine(0)...offset-s/h2(14) 00(sine)
0a 2 00...FF LFO1 Speed 1(0)...256(FF) 53(84)
0c 1 00...7F LFO1 Delay 0...127 0
0d 2 00...FF LFO2 Speed 1(0)...256(FF) 1F(32)
0f 1 00...02 Sync Mode off(0),vco1 mastter to slave(1), vco2 to vco1(2) 0(off)
10 1 00...7F Sync Pitch -64...+63 40(+0)
11 1 00...7F Sync Pitch Depth -64...+63 40(+0)
12 1 00...04 Sync Pitch Source fixed(0),PEG(1),FEG(2),LFO1(3), 00(fixed)
LFO2(4)
13 1 01...03 Sync Pitch Mod Switch master(1),slave(2),both(3) *5 03(both)
14 1 00...7F FM Depth -64...+63 40(+0)
15 1 00...04 FM Source 1 fixed(0),PEG(1),FEG(2),LFO1(3), 00(fixed)
LFO2(4)
16 1 00...07 FM Source 2 VCO2 freq(0),VCO1(1),VCO1-sub(2), 00(VCO2 freq)
PEG(3),FEG(4),LFO1(5),LFO2(6),VCO2 output(7)
17 1 00...04 VCO1 Wave saw(0),pulse(1),saw2(2),mix(3) *3 00(saw)
multi-saw(4)
00...06 VCO1 Wave saw(0),pulse(1),inner1(2), *4
inner2(3),inner3(4),square(5),noise(6)
18 1 00...7F VCO1 Pitch Coarse -64...+63 semitone 40(+0)
19 1 0E...72 VCO1 Pitch Fine -50...+50 cent 40(+0)
1a 1 00...7F VCO1 Edge 0...127 64(100)
1b 1 00...7F VCO1 Pulse Width 0%(0)...50%(40)...99%(7F) *7 40(50%)
00...7F VCO1 Mix 0...127 *8
1c 1 00...7F VCO1 PWM Depth -64...+63 *7 40(+0)
00...7F Detune 0...127 *8
1d 1 00...07 VCO1 PWM Source fixed(0),PEG(1),FEG(2), *7 04(LFO2)
LFO1(3),LFO2(4),LFO2-phase(5),
LFO2-fast(6),VCO2(7)
1e 2 01...FF VCO1 Pitch Mod Depth -127...+127 80(+0)
20 1 00...05 VCO2 Wave saw(0),pulse(1),saw2(2),mix(3) 00(saw)
triangle(4),sine(5)
21 1 00...7F VCO2 Pitch Coarse -64...+63 semitone 40(+0)
22 1 0E...72 VCO2 Pitch Fine -50(0E)...+50 cent(72) 40(+0)
23 1 00...7F VCO2 Edge 0...127 *9 7F(127)
24 1 00...7F VCO2 Pulse Width 0%(0)...50%(40)...99%(7F) *9 40(50%)
25 1 00...7F VCO2 PWM Depth -64...+63 *9 40(+0)
00...7F VCO2 X-MOD Depth -64...+63 *10
26 1 00...07 VCO2 PWM Source fixed(0),PEG(1),FEG(2), *9 04(LFO2)
LFO1(3),LFO2(4),LFO2-phase(5),
LFO2-fast(6),VCO1(7)
00...04 VCO2 X-MOD Source fixed(0),PEG(1),FEG(2), *10
LFO1(3),LFO2(4)
27 2 01...FF VCO2 Pitch Mod Depth -127...+127 80(+0)
29 1 00...7F Mixer VCO1 Level 0...127 7F(127)
2a 1 00...7F Mixer VCO2 Level 0...127 0
2b 1 00...7F Mixer Ring Mod Level 0...127 0
2c 1 00...7F Mixer Noise Level 0...127 0
2d 1 00...7F FilterEG Attack Time 0...127 0
2e 1 00...7F FilterEG Decay Time 0...127 40(64)
2f 1 00...7F FilterEG Sustain Level 0...127 7F(127)
30 1 00...7F FilterEG Release Time 0...127 55(85)
31 1 00...7F HPF Cutoff Freq 0(thru)...127 00(thru)
32 1 00...05 VCF Filter Type LPF-24dB(0),LFP-18dB(1), 00(LPF-24dB)
LPF-12dB(2),BPF(3),HPF-12dB(4),
BEF(5)
33 1 00...7F VCF Filter Cutoff 0...127 64(100)
34 1 0D...7F VCF Filter Resonance -12(0D)...0(19)...+102(7F) 19(+0)
35 2 00...FF FilterEG Depth -128...+127 A0(+32)
37 1 00...7F FillrEG Velocity Sens -64...+63 40(+0)
38 1 20...7F VCF Keyboard Track -32...+63 40(+0)
39 1 00...7F VCF Filter Mod Depth -64...+63 40(+0)
3a 1 00...7F AmpEG Attack Time 0...127 0
3b 1 00...7F AmpEG Decay Time 0...127 40(64)
3c 1 00...7F AmpEG Sustain Level 0...127 7F(127)
3d 1 00...7F AmpEG Release Time 0...127 24(36)
3e 1 00...7F VCA Feedback Level 0...127 0
3f 1 00...7F VCA Volume 0...127 69(105)
40 1 00...7F AmpEG Velocity Sens -64...+63 40(+0)
41 1 00...7F VCA Amp Mod Depth -64...+63 40(+0)
42 1 00...8F Gutitar Amp.Simulator Dry/Wet D63>W(1)...D=W(40)...D<W63(7F) 01(D63>W)
