MIDI Implementation Chart
YAMAHA [ DESKTOP CONTROL SYNTHESIZER ] Date:20-DEC-2000
Model AN200 MIDI Implementation Chart Version : 1.0
Transmitted Recognized Remarks
Function...
Basic Default 1 - 4 1 - 4
Channel Changed 1 - 16 1 - 16
Default 3 3
Mode Messages x 3,4 (m=1) *1
Altered ************** x
Note 1 - 127 0 - 127
Number : True voice ************** 0 - 127
Velocity Note ON o 9nH,v=1-127 o 9nH,v=1-127
Note OFF o 9nH,v=0 x
After Key's x x
Touch Ch's x o
Pitch Bend x o 0-24 semi
0,32 x o Bank Select
1,5,7,10 o o
11 x o
6,38 o o Data Entry
Control 64,65 x o
71-75 o o Sound Controller
Change 94 o o Effect Depth
98-99 o o NRPN LSB,MSB
16,18,19,80-83 o o Knob Control
Prog o o 0 - 127
Change : True # ************** 0 - 127
System Exclusive o o
: Song Pos. o *3 o *2
Common : Song Sel. x x
: Tune x x
System : Clock o *3 o *4
Real Time: Commands o *3 o *2
Aux :All Sound off x o(120,126,127)
:Reset All Cntrls x o(121)
:Local ON/OFF x x
:All Notes OFF x o(123-125)
Mes- :Active Sense o o
sages:Reset x x
Notes: *1 m is always treated as "1" regardless of its value.
*2 if MIDI control is in or in/out
*3 if MIDI control is out or in/out
*4 if MIDI sync is external
Mode 1 : OMNI ON , POLY Mode 2 : OMNI ON ,MONO o : Yes
Mode 3 : OMNI OFF, POLY Mode 4 : OMNI OFF,MONO x : No
