MIDI Data Format
138
Appendix
*1 : MSB bit 2-0 -> bit 9-7
LSB bit 6 -0 -> bit 6-0
*2 : This should be transmitted after sending Step Seq Gate Time LSB n.
<2-10>
MIDI Parameter Change table (User Song)
Address Size Data Prameter Description Default
(H) (H) (H)
6s mm 00 2 00 - FF, 100-17F, PATTERN NUM P.001-P.256, U.001-U128, End, ---- P.001
3FFE, 3FFF
02 2 14 - 12C, 3FFF BPM 20.0 - 300.0, ---- 140.0
04 2 01-C8, FF PLAY FX GATETIME 01-200, ---- 100
06 1 00 - 03, 7F BEAT 16, 12, 8, ---- 16
07 1 32 - 53, 7F SWING 50
08 1 28 - 58, 7F PITCH -24 - 24, ---- 0
09 1 00 - 01, 7F LOOP TYPE For, bACk, ---- For
0A 1 00-0F, 7F (*1) TRACK MUTE oooo-____, ---- oooo
TOTAL SIZE 0B
s = song number
mm = measure (0:1st, 1:2nd... 7f:128th)
Address Size Data Prameter Description Default
(H) (H) (H)
7s mm 00 2 00 - FF, 100-17F, PATTERN NUM P.001-P.256, U.001-U128, End, ---- P.001
3FFE, 3FFF
02 2 14 - 12C, 3FFF BPM 20.0 - 300.0, ---- *2 140.0
04 2 01-C8, FF PLAY FX GATETIME 01-200, ---- 100
06 1 00 - 03, 7F BEAT 16, 12, 8, ---- 16
07 1 32 - 53, 7F SWING 50
08 1 28 - 58, 7F PITCH -24 - 24, ---- 0
09 1 00 - 01, 7F LOOP TYPE For, bACk, ---- For
0A 1 00-0F, 7F (*1) TRACK MUTE oooo-____, ---- oooo
TOTAL SIZE 0B
s = song number
mm = measure (0:129th, 1:130th... 7f:256th)
*1 bit 0: Synth Track, bit1: Rhythm Track 1, bit2:Rhythm Track 2, bit3:Rhythm Track 3, Track(n) is muted when bit(n) = 1.
*2 BPM = ((1st & 03h) * 128 + 2nd) + ((1st & 78h)/8)/10
<3-1>
AN1x Parameter Base Address
MODEL ID = 5C (AN1x)
Parameter Address Description
(H) (M) (L)
Current Voice 10 00 00 AN1x Current Voice Common
10 0E 00 AN1x Current Voice Step Seq Pattern
10 10 00 AN1x Current Voice Scene1
User Voice 11
:
11
00
:
7F
00
:
00
AN1x User Voice 1
:
AN1x User Voice 128
