125
MIDI Data Format
Appendix
0B 1 00...7F Sync Pitch -64...+63 40(+0)
0C 1 00...7F FM Depth -64...+63 40(+0)
0D 1 00...7F Mixer Noise Level 0...127 0
0E 1 00...05 VCF Filter Type LPF-24dB(0),LFP-18dB(1), 00(LPF-24dB)
LPF-12dB(2),BPF(3),HPF-12dB(4),
BEF(5)
0F 1 00...7F VCF Filter Cutoff 0...127 64(100)
10 1 0D...7F VCF Filter Resonance -12(0D)...0(19)...+102(7F) 19(+0)
11 2 00...FF FilterEG Depth -128...+127 A0(+32)
13 1 00...7F VCO1/2 Balance -64...0...+63 40(+0)
14 1 00...7F Volume 0...127 64(100)
15 1 00...7F Pan CENTER(0),L63...C...R63(1...64...127) 40(64)
16 1 00...7F Effect Send 0...127 0
17 1 00...7F Effect parameter refer to Effect Type List <Table 2-4> 0
TOTAL SIZE 18
mm = 00 ~ 7F : User Voice Scene-1 No.1 ~ User Voice Scene-1 No.128
<1-6>
MIDI Bulk Dump Parameter table ( AN200 Current Scene-2 )
Address Size Data Prameter Name Description Default
(H) (H) (H)
10 31 00 2 00...FF LFO1 Speed 1(0)...256(FF) 53(84)
02 1 00...7F AmpEG Attack Time 0...127 0
03 1 00...7F AmpEG Decay Time 0...127 40(64)
04 1 00...7F AmpEG Sustain Level 0...127 7F(127)
05 1 00...7F AmpEG Release Time 0...127 24(36)
06 1 00...7F FilterEG Attack Time 0...127 0
07 1 00...7F FilterEG Decay Time 0...127 40(64)
08 1 00...7F FilterEG Sustain Level 0...127 7F(127)
09 1 00...7F FilterEG Release Time 0...127 55(85)
0A 1 00...7F Portamento Time 0...127 2C(44)
0B 1 00...7F Sync Pitch -64...+63 40(+0)
0C 1 00...7F FM Depth -64...+63 40(+0)
0D 1 00...7F Mixer Noise Level 0...127 0
0E 1 00...05 VCF Filter Type LPF-24dB(0),LFP-18dB(1), 00(LPF-24dB)
LPF-12dB(2),BPF(3),HPF-12dB(4),
BEF(5)
0F 1 00...7F VCF Filter Cutoff 0...127 64(100)
10 1 0D...7F VCF Filter Resonance -12(0D)...0(19)...+102(7F) 19(+0)
11 2 00...FF FilterEG Depth -128...+127 A0(+32)
13 1 00...7F VCO1/2 Balance -64...0...+63 40(+0)
14 1 00...7F Volume 0...127 64(100)
15 1 00...7F Pan CENTER(0),L63...C...R63(1...64...127) 40(64)
16 1 00...7F Effect Send 0...127 0
17 1 00...7F Effect parameter refer to Effect Type List <Table 2-4> 0
TOTAL SIZE 18
mm = 00 ~ 7F : User Voice Scene-2 No.1 ~ User Voice Scene-2 No.128
<1-7>
MIDI Bulk Dump Parameter table ( Current Step Seq )
Address Size Data Prameter Name Description Default
(H) (H) (H)
10 0e 00 1 04,06,07 Step Seq Base Unit 1/8(4)...1/12(6)...1/16(7) 07(1/16)
01 1 08,0C,10 Step Seq Length 8step(8),12step(C),16steps(10) 10
02 1 NOT USED --
03 1 NOT USED --
04 1 NOT USED --
05 1 NOT USED --
06 1 00...7F Step Seq Note No 1 C-2(0)...G8(7F) C3(3C)
07 1 00...7F Step Seq Note No 2 C-2(0)...G8(7F) C3(3C)
08 1 00...7F Step Seq Note No 3 C-2(0)...G8(7F) C3(3C)
09 1 00...7F Step Seq Note No 4 C-2(0)...G8(7F) C3(3C)
0A 1 00...7F Step Seq Note No 5 C-2(0)...G8(7F) C3(3C)
0B 1 00...7F Step Seq Note No 6 C-2(0)...G8(7F) C3(3C)
0C 1 00...7F Step Seq Note No 7 C-2(0)...G8(7F) C3(3C)
0D 1 00...7F Step Seq Note No 8 C-2(0)...G8(7F) C3(3C)
0E 1 00...7F Step Seq Note No 9 C-2(0)...G8(7F) C3(3C)
0F 1 00...7F Step Seq Note No 10 C-2(0)...G8(7F) C3(3C)
10 1 00...7F Step Seq Note No 11 C-2(0)...G8(7F) C3(3C)
11 1 00...7F Step Seq Note No 12 C-2(0)...G8(7F) C3(3C)
12 1 00...7F Step Seq Note No 13 C-2(0)...G8(7F) C3(3C)
13 1 00...7F Step Seq Note No 14 C-2(0)...G8(7F) C3(3C)
14 1 00...7F Step Seq Note No 15 C-2(0)...G8(7F) C3(3C)
15 1 00...7F Step Seq Note No 16 C-2(0)...G8(7F) C3(3C)
16 1 00...7F Step Seq Velocity 1 rest(0),1...127 100(64)
17 1 00...7F Step Seq Velocity 2 rest(0),1...127 100(64)
18 1 00...7F Step Seq Velocity 3 rest(0),1...127 100(64)
19 1 00...7F Step Seq Velocity 4 rest(0),1...127 100(64)
1A 1 00...7F Step Seq Velocity 5 rest(0),1...127 100(64)
1B 1 00...7F Step Seq Velocity 6 rest(0),1...127 100(64)
1C 1 00...7F Step Seq Velocity 7 rest(0),1...127 100(64)
1D 1 00...7F Step Seq Velocity 8 rest(0),1...127 100(64)
1E 1 00...7F Step Seq Velocity 9 rest(0),1...127 100(64)
1F 1 00...7F Step Seq Velocity 10 rest(0),1...127 100(64)
20 1 00...7F Step Seq Velocity 11 rest(0),1...127 100(64)
21 1 00...7F Step Seq Velocity 12 rest(0),1...127 100(64)
22 1 00...7F Step Seq Velocity 13 rest(0),1...127 100(64)
23 1 00...7F Step Seq Velocity 14 rest(0),1...127 100(64)
24 1 00...7F Step Seq Velocity 15 rest(0),1...127 100(64)
25 1 00...7F Step Seq Velocity 16 rest(0),1...127 100(64)
26 1 00...7F Step Seq Gate Time LSB 1 *1 94%(3C)
27 1 00...7F Step Seq Gate Time LSB 2 *1 94%(3C)
