Yamaha Loopfactory AN200 - Page 131

131
MIDI Data Format
Appendix
<1-10>
MIDI Bulk Dump Parameter table ( User Pattern Voice Scene-1 )
Address Size Data Prameter Name Description Default
(H) (H) (H)
40 mm 00 2 00...FF LFO1 Speed 1(0)...256(FF) 53(84)
02 1 00...7F AmpEG Attack Time 0...127 0
03 1 00...7F AmpEG Decay Time 0...127 40(64)
04 1 00...7F AmpEG Sustain Level 0...127 7F(127)
05 1 00...7F AmpEG Release Time 0...127 24(36)
06 1 00...7F FilterEG Attack Time 0...127 0
07 1 00...7F FilterEG Decay Time 0...127 40(64)
08 1 00...7F FilterEG Sustain Level 0...127 7F(127)
09 1 00...7F FilterEG Release Time 0...127 55(85)
0A 1 00...7F Portamento Time 0...127 2C(44)
0B 1 00...7F Sync Pitch -64...+63 40(+0)
0C 1 00...7F FM Depth -64...+63 40(+0)
0D 1 00...7F Mixer Noise Level 0...127 0
0E 1 00...05 VCF Filter Type LPF-24dB(0),LFP-18dB(1), 00(LPF-24dB)
LPF-12dB(2),BPF(3),HPF-12dB(4),
BEF(5)
0F 1 00...7F VCF Filter Cutoff 0...127 64(100)
10 1 0D...7F VCF Filter Resonance -12(0D)...0(19)...+102(7F) 19(+0)
11 2 00...FF FilterEG Depth -128...+127 A0(+32)
13 1 00...7F VCO1/2 Balance -64...0...+63 40(+0)
14 1 00...7F Volume 0...127 64(100)
15 1 00...7F Pan CENTER(0),L63...C...R63(1...64...127) 40(64)
16 1 00...7F Effect Send 0...127 0
17 1 00...7F Effect parameter refer to Effect Type List <Table 2-4> 0
TOTAL SIZE 18
mm = 00 ~ 7F : User Voice Scene-1 No.1 ~ User Voice Scene-1 No.128
<1-11>
MIDI Bulk Dump Parameter table ( User Pattern Voice Scene-2 )
Address Size Data Prameter Name Description Default
(H) (H) (H)
41 mm 00 2 00...FF LFO1 Speed 1(0)...256(FF) 53(84)
02 1 00...7F AmpEG Attack Time 0...127 0
03 1 00...7F AmpEG Decay Time 0...127 40(64)
04 1 00...7F AmpEG Sustain Level 0...127 7F(127)
05 1 00...7F AmpEG Release Time 0...127 24(36)
06 1 00...7F FilterEG Attack Time 0...127 0
07 1 00...7F FilterEG Decay Time 0...127 40(64)
08 1 00...7F FilterEG Sustain Level 0...127 7F(127)
09 1 00...7F FilterEG Release Time 0...127 55(85)
0A 1 00...7F Portamento Time 0...127 2C(44)
0B 1 00...7F Sync Pitch -64...+63 40(+0)
0C 1 00...7F FM Depth -64...+63 40(+0)
0D 1 00...7F Mixer Noise Level 0...127 0
0E 1 00...05 VCF Filter Type LPF-24dB(0),LFP-18dB(1), 00(LPF-24dB)
LPF-12dB(2),BPF(3),HPF-12dB(4),
BEF(5)
0F 1 00...7F VCF Filter Cutoff 0...127 64(100)
10 1 0D...7F VCF Filter Resonance -12(0D)...0(19)...+102(7F) 19(+0)
11 2 00...FF FilterEG Depth -128...+127 A0(+32)
13 1 00...7F VCO1/2 Balance -64...0...+63 40(+0)
14 1 00...7F Volume 0...127 64(100)
15 1 00...7F Pan CENTER(0),L63...C...R63(1...64...127) 40(64)
16 1 00...7F Effect Send 0...127 0
17 1 00...7F Effect parameter refer to Effect Type List <Table 2-4> 0
TOTAL SIZE 18
mm = 00 ~ 7F : User Voice Scene-2 No.1 ~ User Voice Scene-2 No.128
* This Bulk Dump should be transmitted after sending User Voice Bulk (20 mm 00).
