135
MIDI Data Format
Appendix
<2-5>
MIDI Parameter Change table (User Voice EFFECT)
Address Size Data Prameter Name Description Default
(H) (H) (H) (H)
30 nn 00 1 00 - 03 EFFECT TYPE MSB refer to Effect Type List <Table 2-4> 00
01 1 00 - 02 EFFECT TYPE LSB refer to Effect Type List <Table 2-4> 00
02 1 00 - 7F EFFECT PARAMETER refer to Effect Type List <Table 2-4> 00
TOTAL SIZE 3
nn = Pattern Number
<2-6>
MIDI Parameter Change table ( MULTI PART )
Address Size Data Prameter Name Description Default
(H) (H) (H) (H)
08 pp 00 1 (RESERVED) --
01 1 (RESERVED) --
02 1 (RESERVED) --
03 1 (RESERVED) --
04 1 (RESERVED) --
05 1 00 - 7F VOLUME 0 - 127 64
06 1 00 - 7F PAN CENTER/RANDOM (*1) (0),L63...C...R63(1...64...127) 40
07 1 00 - 7F EFFECT1 SEND 0 - 127 00
08 1 (RESERVED) --
09 1 (RESERVED) --
0A 1 00 - 7F FILTER CUTOFF FREQUENCY (*2) -64 - +63 40
0B 1 00 - 7F FILTER RESONANCE (*2) -64 - +63 40
0C 1 (RESERVED) --
0D 1 (RESERVED) --
0E 1 (RESERVED) --
TOTAL SIZE 0F
pp = Part Number ( 00 - 02 : Rhythm Track 1 - 3, 08 : Synth Track )
*1 CENTER when pp = 08(Synth Track), RANDOM when pp = 0,1,2(Rhythm Track)
*2 reserved when pp = 08(Synth Track)
<2-7>
MIDI Parameter Change table (User Voice MULTI PART )
Address Size Data Prameter Name Description Default
(H) (H) (H) (H)
4p nn 00 1 (RESERVED) --
01 1 (RESERVED) --
02 1 (RESERVED) --
03 1 (RESERVED) --
04 1 (RESERVED) --
05 1 00 - 7F VOLUME 0 - 127 64
06 1 00 - 7F PAN CENTER/RANDOM (*1) (0),L63...C...R63(1...64...127) 40
07 1 00 - 7F EFFECT1 SEND 0 - 127 00
08 1 (RESERVED) 28
09 1 (RESERVED) 00
0A 1 00 - 7F FILTER CUTOFF FREQUENCY (*2) -64 - +63 40
0B 1 00 - 7F FILTER RESONANCE (*2) -64 - +63 40
0C 1 (RESERVED) --
0D 1 (RESERVED) --
0E 1 (RESERVED) --
TOTAL SIZE 0F
nn = Pattern Number
p = Part Number ( 0 - 2 : Rhythm Track 1 - 3, 8 : Synth Track )
*1 CENTER when pp = 08(Synth Track), RANDOM when pp = 0,1,2(Rhythm Track)
*2 reserved when pp = 08(Synth Track)
<2-8>
MIDI Parameter Change table ( Rhythm Track Current Step Seq Pattern )
Address Size Data Prameter Name Description Default
(H) (H) (H)
10 0p 00 1 NOT USED --
01 1 NOT USED --
02 1 NOT USED --
03 1 NOT USED --
04 1 NOT USED --
05 1 NOT USED --
06 1 00...78 Step Seq Inst 1 Ba1C(0)...DgW7(78) SD10
07 1 00...78 Step Seq Inst 2 Ba1C(0)...DgW7(78) SD10
08 1 00...78 Step Seq Inst 3 Ba1C(0)...DgW7(78) SD10
09 1 00...78 Step Seq Inst 4 Ba1C(0)...DgW7(78) SD10
0A 1 00...78 Step Seq Inst 5 Ba1C(0)...DgW7(78) SD10
0B 1 00...78 Step Seq Inst 6 Ba1C(0)...DgW7(78) SD10
0C 1 00...78 Step Seq Inst 7 Ba1C(0)...DgW7(78) SD10
0D 1 00...78 Step Seq Inst 8 Ba1C(0)...DgW7(78) SD10
0E 1 00...78 Step Seq Inst 9 Ba1C(0)...DgW7(78) SD10
0F 1 00...78 Step Seq Inst 10 Ba1C(0)...DgW7(78) SD10
10 1 00...78 Step Seq Inst 11 Ba1C(0)...DgW7(78) SD10
11 1 00...78 Step Seq Inst 12 Ba1C(0)...DgW7(78) SD10
12 1 00...78 Step Seq Inst 13 Ba1C(0)...DgW7(78) SD10
13 1 00...78 Step Seq Inst 14 Ba1C(0)...DgW7(78) SD10
14 1 00...78 Step Seq Inst 15 Ba1C(0)...DgW7(78) SD10
15 1 00...78 Step Seq Inst 16 Ba1C(0)...DgW7(78) SD10
16 1 00...7F Step Seq Velocity 1 rest(0),1...127 100(64)
17 1 00...7F Step Seq Velocity 2 rest(0),1...127 100(64)
18 1 00...7F Step Seq Velocity 3 rest(0),1...127 100(64)
