Yamaha MOX6 Service Manual

MOX6/MOX8
9
RANK : Japan only
∗
: New Parts
（新規部品）
部品名
REF NO.
PART NO. DESCRIPTION

REMARKS
QTY RANK
10
20
30
40
40
50
60
80
85
90
100
110
120
151
152
220
--
V9338500
V9338600
V9339200
VZ27170R
--
V3413601
V747740R
VZ303000
VZ302901
WA52510R
WE774301
WH899400
WF49200R
WW292500
WW292600
V869620R
KEYBOARD ASSEMBLY
KEYBOARD UNIT C61
WHITE KEY 16NW C,E,G,B
WHITE KEY 16NW D,F,A
WHITE KEY 16NW C'
BLACK KEYS
BLACK KEY 16N
RUBBER CONTACT
RUBBER CONTACT
FELT L 11X827 WH
FELT U836
CUSHION SHEET
SCREW TP #B +BIND
BIND HEAD TAPPING SCREW
BIND HEAD TAPPING SCREW-P
CIRCUIT BOARD
CIRCUIT BOARD
CONNECTOR ASSEMBLY
16NW-C61 2M NON-AF
16N-W CEGB
16N-W DFA
16N-W C'
16N
16N SUBCON
16N-2M OCT 2M
16N-2M 13K 2M
827 11 WHITE
836 5 WHITE
3.0X8 MFZN2W3
3.0X12 MFZN2W3 SP
3.0X20 MFZN2W3
61L 16N-61
61H 16N-61
16N-2M-C61 L=21
１６ＮＷ−Ｃ６１鍵盤Ａｓｓｙ
１６ＮＷ−Ｃ６１鍵盤
白鍵Ａｓｓｙ
白鍵Ａｓｓｙ
白鍵Ａｓｓｙ
黒鍵
黒鍵
接点ゴム１６Ｎ２Ｍ
接点ゴム１６Ｎ２Ｍ
フェルトＬ
フェルトＵ
クッションシート
Ｂタイト＋ＢＩＮＤ
Ｐタイト＋ＢＩＮＤ
Ｐタイト＋ＢＩＮＤ
シート６１Ｌ
シート６１Ｈ
中継束線
MOX6
(WV65380)
(VZ27171)
C1-B1,C2-B2,C3-B3,C4-B4
C5-C6
5
5
5
5
4
7
13
21
04
03
02
02
04
04
02
02
01
01
01
01
01
*
*

Yamaha MOX6 Specifications

General

Keyboard	61 keys, semi-weighted
Wave ROM	355MB
Sound Engine	AWM2
Drum Kits	64
Arpeggiator	6, 720 types
Display	240 x 64 dot backlit LCD
Weight	7.0 kg
Effects	Reverb, Chorus, Insertion Effects, Master Effect, Part EQ
Sequencer	16-track, 226, 000 notes
Connectivity	USB, MIDI (In/Out/Thru), Phones, Output (L/Mono, R), Foot Controller, Foot Switch, DC In
Polyphony	64 voices
Preset Voices	1, 024 Normal Voices + 64 Drum Kits
Dimensions	1, 030 x 358 x 125 mm
