60
MOX6/MOX8
*
If you execute the test no.46, Factory Set, the user's data may be lost.
Therefore, back up the user's data in advance.
The test program has two modes.
In the manual mode, it can be operated by switches on the panel.
In the MIDI mode, it can be controlled by MIDI signal. Refer to page 69 (MIDI MODE) for more details.
MANUAL MODE
1. Measurement conditions
1-1 Power Supply
Use PA-150A or PA-150 (AC adaptor).
1-2 Measuring instruments
• Level meter (with a JIS-C fi lter)
• Frequency counter (The number of decimal places of measurable value is more than 3.)
Note: The input impedance of the measuring instrument is more than 1M ohm.
OUTPUT [L/MONO],[R] terminal: 10k ohm load
[PHONES] L/R terminal: 33 ohm load
1-3 Jigs
Foot pedal (FC-3), Foot switch (FC-4 or FC-5), Foot controller (FC-7 or FC-9), MIDI cable, USB cable (A type-B type), USB fl ash
memory, Monitor speaker, MIDI monitor, Oscillator, PC(Personal Computer)(*1)
*1: The PC to be connected to the USB [TO HOST] terminal must have the following specifi cations.
• Terminal: Built in USB interface
• OS, CPU, Memory
OS: [Windows XP Professional SP3 / Windows XP Home Edition SP3]
CPU: Intel Pentium 2.0GHz or more
Memory: 512MB or more
OS: [Windows Vista SP1 (32/64bit)]
CPU: Intel Pentium 2.0GHz or more
Memory: 1GB or more
OS: [Windows 7 (32/64bit)]
CPU: Intel Pentium 2.0GHz or more
Memory: 1GB or more
• Drivers, Tools:
1R 6RIWZDUH 9HUVLRQ 6XSSOLHU
<DPDKD6WHLQEHUJ86%'ULYHU 9 '0,6RIW*URXS
$VLR/RRS%DFNH[H 9 '0,6RIW*URXS
■
TEST PROGRAM
