Yamaha MT-09SP 2021 - FRONT BRAKE

4-25
FRONT BRAKE
EAS20030
FRONT BRAKE
Removing the front brake pads
Order Job/Parts to remove Q’ty Remarks
The following procedure applies to both of
the front brake calipers.
1 Brake pad clip 2
2 Brake pad pin 1
3 Brake pad spring 1
4 Brake pad 2
5 Front brake caliper 1
6 Bleed screw 1
12
3
4
5
6
5 N・m (0.5 kgf・m, 3.7 lb・ft)
35 N・m (3.5 kgf・m, 26 lb・ft)
