5-62
OIL PAN
EAS31068
REMOVING THE OIL PAN
1. Remove:
• Oil pan
• Oil pan gasket
TIP
Loosen each bolt 1/4 of a turn at a time, in stag-
es and in a crisscross pattern. After all of the
bolts are fully loosened, remove them.
EAS31069
CHECKING THE OIL STRAINER
1. Check:
• Oil strainer
Damage → Replace.
Contaminants → Clean with solvent.
EAS31070
INSTALLING THE OIL PAN
1. Install:
• Oil pan gasket
• Oil pan
TIP
Tighten the oil pan bolts in stages and in a criss-
cross pattern.
2. Install:
•Gasket
• Engine oil drain bolt
Oil pan bolt
13 N·m (1.3 kgf·m, 9.6 lb·ft)
LOCTITE®
Engine oil drain bolt
43 N·m (4.3 kgf·m, 32 lb·ft)
New
T
R
.
.
New
T
R
.
.
