Yamaha MT-09SP 2021 - Page 160

4-27
FRONT BRAKE
Removing the front brake master cylinder
* For MTN890
** For MTN890D
Order Job/Parts to remove Q’ty Remarks
10 Brake hose union bolt 1
11 Brake hose gasket 2
12 Brake hose 1
13 Front brake master cylinder holder 1
14 Front brake master cylinder 1
15 Front brake light switch 1
14
12
13
15
15
10
11
11
*
*
*
**
**
**
New
New
S
3.5 N
•
m (0.35 kgf
•
m, 2.6 lb
•
ft)
T
.R.
7 N
•
m (0.7 kgf
•
m, 5.2 lb
•
ft)
T
.R.
16 N
•
m (1.6 kgf
•
m, 12 lb
•
ft)
T
.R.
4.0 N
•
m (0.40 kgf
•
m, 3.0 lb
•
ft)
T
.R.
1.2 N
•
m (0.12 kgf
•
m, 0.88 lb
•
ft)
T
.R.
1.2 N
•
m (0.12 kgf
•
m, 0.88 lb
•
ft)
T
.R.
1.0 N
•
m (0.10 kgf
•
m, 0.73 lb
•
ft)
T
.R.
6 N
•
m (0.6 kgf
•
m, 4.4 lb
•
ft)
T
.R.
1.2 N
•
m (0.12 kgf
•
m, 0.88 lb
•
ft)
T
.R.
30 N
•
m (3.0 kgf
•
m, 22 lb
•
ft)
T
.R.
