Yamaha MT-09SP 2021 - Page 240

5-13
ENGINE REMOVAL
Removing the engine
Order Job/Parts to remove Q’ty Remarks
16 Engine mounting nut (upper) 1
17 Engine mounting bolt (rear lower side) 1
18 Engine mounting bolt (rear upper side) 1
19 Engine 1
20 Engine mounting adjust bolt 2
LT
LT
LT
LT
20
20
19
16
18
17
25 N•m (2.5 kgf•m, 18 lb•ft)
25 N•m (2.5 kgf•m, 18 lb•ft)
45 N•m (4.5 kgf•m, 33 lb•ft)
60 N•m (6.0 kgf•m, 44 lb•ft)
60 N•m (6.0 kgf•m, 44 lb•ft)
105 N•m (10.5 kgf•m, 77 lb•ft)
45 N•m (4.5 kgf•m, 33 lb•ft)
55 N•m (5.5 kgf•m, 41 lb•ft)
7 N・m (0.7 kgf・m, 5.2 lb・ft)
55 N•m (5.5 kgf•m, 41 lb•ft)
