CAMSHAFTS
Removing the camshafts
Order Job/Parts to remove Q’ty Remarks
12 Intake camshaft sprocket 1
13 Exhaust camshaft sprocket 1
14 Timing chain bolt 1
15 Dowel pin 1
16 Timing chain guide (intake side) 1
17 Timing chain 1
E
14
(7)
(8)
(4)
(4)
15 16 17
New
New
10 N
•
m (1.0 kgf
•
m, 7.4 lb
•
ft)
T
.R.
10 N
•
m (1.0 kgf
•
m, 7.4 lb
•
ft)
T
.R.
12 N
•
m (1.2 kgf
•
m, 8.9 lb
•
ft)
T
.R.
10 N
•
m (1.0 kgf
•
m, 7.4 lb
•
ft)
T
.R.
10 N
•
m (1.0 kgf
•
m, 7.4 lb
•
ft)
T
.R.
24 N
•
m (2.4 kgf
•
m, 18 lb
•
ft)
T
.R.
M
13
12
