5-64
CRANKCASE
Separating the crankcase
* Following the tightening order, loosen the bolt one by one, and then retighten it to the specific torque and the
specified angle.
** YAMAHA Bond No. 1215B®
Order Job/Parts to remove Q’ty Remarks
1 Oil filter cartridge 1
2 Oil filter cartridge union bolt 1
3 Oil pressure switch 1
4 Oil pressure switch joint 1
5 Gear position sensor 1
6 Neutral switch 1
7 Clutch cable holder 1
8 Lower crankcase 1
9 Dowel pin 3
9
7
6
5
9
9
4
3
8
(2)
(6)
(2)
(4)
(2)
(12)
2
1
E
E
LS
**
E
LT
LT
New
New
LS
New
New
New
E
E
E
E
LT
LT
LT
LT
LS
1st 25 N
•
m (2.5 kgf
•
m, 18 lb
•
ft)
16 N
•
m (1.6 kgf
•
m, 12 lb
•
ft)
*2nd
Specified angle 60°
T.
R.
22 N
•
m (2.2 kgf
•
m, 16 lb
•
ft)
T.R.
1.8 N
•
m (0.18 kgf
•
m, 1.3 lb
•
ft)
T.R.
10 N
•
m (1.0 kgf
•
m, 7.4 lb
•
ft)
T.R.
13 N
•
m (1.3 kgf
•
m, 9.6 lb
•
ft)
T.R.
12 N
•
m (1.2 kgf
•
m, 8.9 lb
•
ft)
T.R.
17 N
•
m (1.7 kgf
•
m, 13 lb
•
ft)
T.R.
70 N
•
m (7.0 kgf
•
m, 52 lb
•
ft)
T.R.
1st 25 N
•
m (2.5 kgf
•
m, 18 lb
•
ft)
20 N
•
m (2.0 kgf
•
m, 15 lb
•
ft)
*2nd
Specified angle 60°
T.
R.
10 N
•
m (1.0 kgf
•
m, 7.4 lb
•
ft)
T.R.
10 N
•
m (1.0 kgf
•
m, 7.4 lb
•
ft)
T.R.
24 N
•
m (2.4 kgf
•
m, 18 lb
•
ft)
T.R.
4.0 N
•
m (0.40 kgf
•
m, 3.0 lb
•
ft)
T.R.
17 N
•
m (1.7 kgf
•
m, 13 lb
•
ft)
T.R.
