Yamaha MT-09SP 2021 - Page 314

5-87
TRANSMISSION
Removing the transmission, shift drum assembly, and shift forks
Order Job/Parts to remove Q’ty Remarks
14 Main axle assembly 1
15 Oil delivery pipe 1
16 O-ring 1
17 Oil nozzle 1
18 Bearing cover plate 1
19 Bearing 1
19
14
15
16
17
New
New
New
18
E
E
E
LT
LT
E
LT
LT
E
E
E
LT
10 N
•
m (1.0 kgf
•
m, 7.4 lb
•
ft)
10 N
•
m (1.0 kgf
•
m, 7.4 lb
•
ft)
12 N
•
m (1.2 kgf
•
m, 8.9 lb
•
ft)
0.5 N
•
m (0.05 kgf
•
m, 0.37 lb
•
ft)
14 N
•
m (1.4 kgf
•
m, 10 lb
•
ft)
