9-10
SYSTEM DIAGRAM
*1. For MTN890D
103
Gear position sen-
sor
G/W
104 — —
105
ABS ECU (Electron-
ic Control Unit)
W/G
106 — —
107
ABS ECU (Electron-
ic Control Unit)
W/Y
108 — —
No. Connected parts
Wire harness
color
