Yamaha QL5 Service Manual

61
QL5/QL1
IC259 XZ414F00 IC W9864G6JH-6
ＩＣ
03
IC260 X5665D00 IC M12L64164A-7TG2Y
ＩＣ
QL5: SDRAM 64M 03
IC260 XZ414F00 IC W9864G6JH-6
ＩＣ
03
IC261 X5665D00 IC M12L64164A-7TG2Y
ＩＣ
QL5: SDRAM 64M 03
IC261 XZ414F00 IC W9864G6JH-6
ＩＣ
03
IC262 X5665D00 IC M12L64164A-7TG2Y
ＩＣ
SDRAM 64M 03
IC262 XZ414F00 IC W9864G6JH-6
ＩＣ
03
IC351 X3693A00 IC SN74LV245APWR
ＩＣ
TRANSCEIVER
IC352 X3693A00 IC SN74LV245APWR
ＩＣ
TRANSCEIVER
IC451 -- IC EP4CE15F23C8N
ＩＣ
FPGA (YE220A0)
*
IC452 YF882B00 IC EPCS4SI8N/T
ＩＣ
EPROM 4M
*
IC453 YD243A00 IC ADP2118ACPZ-R7
ＩＣ
DC-DC CONVERTER
IC551 X7699A00 IC BA00BC0WFP-E2
ＩＣ
REGULATOR (VARIABLE)
IC552 X3803A00 IC TMS320DA150PGE16D
ＩＣ
DSP
IC553 YD750A00 IC AK4125VF-E2
ＩＣ
SRC 07
IC554 YE063B00 IC LC4064V-75TN100C
ＩＣ
CPLD
IC601 X5263A0R IC PCA9516
ＩＣ
I2C HUB 06
IC602 X5263A0R IC PCA9516
ＩＣ
I2C HUB 06
IC651 XT744B0R IC TC74VHCT245AFT
ＩＣ
TRANSCEIVER 02
IC652 X3693A00 IC SN74LV245APWR
ＩＣ
TRANSCEIVER
IC653 XT744B0R IC TC74VHCT245AFT
ＩＣ
TRANSCEIVER 02
IC654 X3693A00 IC SN74LV245APWR
ＩＣ
TRANSCEIVER
-658 X3693A00 IC SN74LV245APWR
ＩＣ
TRANSCEIVER
IC659 XT744B0R IC TC74VHCT245AFT
ＩＣ
TRANSCEIVER 02
IC751 XT744B0R IC TC74VHCT245AFT
ＩＣ
TRANSCEIVER 02
IC801 X3693A00 IC SN74LV245APWR
ＩＣ
QL5: TRANSCEIVER
IC802 X3693A00 IC SN74LV245APWR
ＩＣ
QL5: TRANSCEIVER
IC803 X3693A00 IC SN74LV245APWR
ＩＣ
TRANSCEIVER
IC804 X3693A00 IC SN74LV245APWR
ＩＣ
TRANSCEIVER
IC901 X3693A00 IC SN74LV245APWR
ＩＣ
TRANSCEIVER
IC902 X3693A00 IC SN74LV245APWR
ＩＣ
TRANSCEIVER
IC931 X3693A00 IC SN74LV245APWR
ＩＣ
TRANSCEIVER
IC951 YD184B00 IC BD9329AEFJ
ＩＣ
DC-DC CONVERTER 01
IC952 YD184B00 IC BD9329AEFJ
ＩＣ
QL5: DC-DC CONVERTER 01
IC981 XV890B0R IC TC74VHC14FT-ELK
ＩＣ
INVERTER 01
L101 WG834800 COIL DLW21HN900SQ2L
コイル
01
L151 V3232700 INDUCTANCE (CHIP) 120uH
チップインダクタ
01
L451 WJ018200 COIL INDUCTOR (CHIP) BLM18SG700TN1D
チップインダクタ
01
L452 WJ018200 COIL INDUCTOR (CHIP) BLM18SG700TN1D
チップインダクタ
01
L453 WR368500 COIL
1uH CDRH3D23NP-1R0PC
コイル １Ｕ
02
L454 WJ018200 COIL INDUCTOR (CHIP) BLM18SG700TN1D
チップインダクタ
01
L455 WJ018200 COIL INDUCTOR (CHIP) BLM18SG700TN1D
チップインダクタ
01
L601 WB24830R INDUCTANCE (CHIP) BLM18RK121SN1D
チップインダクタ
01
L602 WB24830R INDUCTANCE (CHIP) BLM18RK121SN1D
チップインダクタ
01
L603 WB24830R INDUCTANCE (CHIP) BLM18RK121SN1D
チップインダクタ
QL5 01
L604 WB24830R INDUCTANCE (CHIP) BLM18RK121SN1D
チップインダクタ
QL5 01
L605 WB24830R INDUCTANCE (CHIP) BLM18RK121SN1D
チップインダクタ
01
L606 WB24830R INDUCTANCE (CHIP) BLM18RK121SN1D
チップインダクタ
01
L951 V5431600 INDUCTANCE (CHIP) 10uH SLF10145T
チップインダクタ
L952 V5431600 INDUCTANCE (CHIP) 10uH SLF10145T
チップインダクタ
QL5
R101 RD45747R CARBON RESISTOR (CHIP) 47.0K 63M J RECT.
チップ抵抗
QL5 01
R102 RD45000R CARBON RESISTOR (CHIP) 0.00 63M J RECT.
チップ抵抗
QL1 01
R103 RD454220 CARBON RESISTOR (CHIP) 22.0 63M J RECT.
チップ抵抗
R104 RD45000R CARBON RESISTOR (CHIP) 0.00 63M J RECT.
チップ抵抗
01
R105 RD45000R CARBON RESISTOR (CHIP) 0.00 63M J RECT.
チップ抵抗
01
R106 RD454220 CARBON RESISTOR (CHIP) 22.0 63M J RECT.
チップ抵抗
R107 RD454680 CARBON RESISTOR (CHIP) 68.0 63M J RECT.
チップ抵抗
01
R108 RD45000R CARBON RESISTOR (CHIP) 0.00 63M J RECT.
チップ抵抗
01
R109 RD45000R CARBON RESISTOR (CHIP) 0.00 63M J RECT.
チップ抵抗
01
R110 RD457100 CARBON RESISTOR (CHIP) 10.0K 63M J RECT.
チップ抵抗
R111 RD454470 CARBON RESISTOR (CHIP) 47.0 63M J RECT.
チップ抵抗
01
R112 RD454220 CARBON RESISTOR (CHIP) 22.0 63M J RECT.
チップ抵抗
-119 RD454220 CARBON RESISTOR (CHIP) 22.0 63M J RECT.
チップ抵抗
R120 RD454470 CARBON RESISTOR (CHIP) 47.0 63M J RECT.
チップ抵抗
01
R121 RD454470 CARBON RESISTOR (CHIP) 47.0 63M J RECT.
チップ抵抗
01
R122 RD454220 CARBON RESISTOR (CHIP) 22.0 63M J RECT.
チップ抵抗
-124 RD454220 CARBON RESISTOR (CHIP) 22.0 63M J RECT.
チップ抵抗
R125 RD45000R CARBON RESISTOR (CHIP) 0.00 63M J RECT.
チップ抵抗
QL5 01
R126 RD45000R CARBON RESISTOR (CHIP) 0.00 63M J RECT.
チップ抵抗
QL1 01
R151 RD456470 CARBON RESISTOR (CHIP) 4.7K 63M J RECT.
チップ抵抗
REF NO.
PART NO.
DESCRIPTION
部品名
REMARKS
QTY RANK
*
: New Parts RANK: Japan only
DSP32(QL5)/DSP16(QL1)

Yamaha QL5 Specifications

General

DJ mixer	-
Product color	Black
Video capability	No
Channels quantity	72 channels
Supported sample rates	44.1, 48 kHz
Digital sound processing	- bit
Phantom power	48 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	200 W
Total Harmonic Distortion (THD)	0.05 %

Weight and Dimensions

Depth	563 mm
Width	828 mm
Height	272 mm
Weight	21800 g
