Yamaha QL5 Service Manual

QL5/QL1
18
■
CONTROL PANEL L ASSEMBLY
（コンパネＬAss'y）
(QL5)
180
280
250
240
310
200
10
210
320
290
165
45
40
60
60
50
70
80
370
371
372
360
340
330
190
350
220
235
230
360
90
100
110
110
130
120
20
30
100
90
155
170
160
140
135
145
150
390
400
300
LCD ASSEMBLY: See page 21.
（LCDAssy）
CONTROL PANEL L CS
: See page 20.
（コンパネLCS）
<
Bottom view /
下面 >

Yamaha QL5 Specifications

General

DJ mixer	-
Product color	Black
Video capability	No
Channels quantity	72 channels
Supported sample rates	44.1, 48 kHz
Digital sound processing	- bit
Phantom power	48 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	200 W
Total Harmonic Distortion (THD)	0.05 %

Weight and Dimensions

Depth	563 mm
Width	828 mm
Height	272 mm
Weight	21800 g
