Yamaha QL5 Service Manual

66
QL5/QL1
IC301 X3693A00 IC SN74LV245APWR
ＩＣ
TRANSCEIVER
IC302 YD685A00 IC TLC5941PWPR
ＩＣ
LED DRIVER 04
IC303 X7284A01 IC SN74LV138APWR
ＩＣ
DECODER 01
*
LD101 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
SENDS ON FADER 1
*
LD102 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
SENDS ON FADER 2
*
LD103 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
SENDS ON FADER 3
*
LD104 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
SENDS ON FADER 4
*
LD105 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
SENDS ON FADER 5
*
LD106 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
SENDS ON FADER 6
*
LD107 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
SENDS ON FADER 7
*
LD108 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
SENDS ON FADER 8
*
LD109 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
SENDS ON FADER 9
*
LD110 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
SENDS ON FADER 10
*
LD 111 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
SENDS ON FADER 11
*
LD112 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
SENDS ON FADER 12
*
LD113 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
SENDS ON FADER 13
*
LD114 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
SENDS ON FADER 14
*
LD115
ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
SENDS ON FADER 15
*
LD116 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
SENDS ON FADER 16
*
LD201 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
EQUALIZER LOW
*
LD202 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
EQUALIZER LOW-MID
*
LD203 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
EQUALIZER HIGH-MID
*
LD204 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
EQUALIZER HIGH
LD205 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
USER DEFINED KEYS 1 01
LD206 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
USER DEFINED KEYS 2 01
LD207 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
USER DEFINED KEYS 3 01
LD208 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
USER DEFINED KEYS 4 01
LD209 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
USER DEFINED KEYS 5 01
LD210 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
USER DEFINED KEYS 6 01
LD211 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
USER DEFINED KEYS 7 01
LD212 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
USER DEFINED KEYS 8 01
LD213 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
USER DEFINED KEYS 9 01
LD214 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
USER DEFINED KEYS 10 01
LD215 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
USER DEFINED KEYS 11 01
LD216
ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
USER DEFINED KEYS 12 01
*
LD217 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
QL5: FADER BANK 1-32
QL1: FADER BANK 1-16
*
LD218 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
QL5: FADER BANK 33-64
QL1: FADER BANK 17-32
*
LD219 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
FADER BANK ST IN/DCA
*
LD220 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
FADER BANK MIX/MATRIX
LD221 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
FADER BANK A 01
LD222 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
FADER BANK B 01
*
LD301 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
MASTER A SEL
LD302 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
MASTER A CUE 01
LD303 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
MASTER A OVER 01
LD304 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
MASTER A -6
LD305 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
MASTER A -12
LD306 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
MASTER A -18
LD307 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
MASTER A -30 01
LD308 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
MASTER A -60 01
LD309 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
MASTER A ON 01
*
LD310 ZJ971300 LED (CHIP) GREEN ASMT-SGB5-ZX3Y3
チップＬＥＤ
MASTER B SEL
LD311 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
MASTER B CUE 01
LD312 WY781500 LED (CHIP) RED SML-D12U8WT86(Q/R)
チップＬＥＤ
MASTER B OVER 01
LD313 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
MASTER B -6
LD314 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
MASTER B -12
LD315 WW948900 LED (CHIP) ORANGE SML-D12D8WT86(R/S)
チップＬＥＤ
MASTER B -18
LD316 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
MASTER B -30 01
LD317 WY781600 LED (CHIP) GREEN SML-D12M8WT86(N/P)
チップＬＥＤ
MASTER B -60 01
LD318 ZF070000 LED (CHIP) ORANGE LO E6SF-BABB-24-1
チップＬＥＤ
MASTER B ON 01
LD319 ZD114500 LED (CHIP) RED/GREEN/BLUE SMLV56RGB1W1(5/6/7)
チップＬＥＤ
MASTER A 03
LD320 ZD114500 LED (CHIP) RED/GREEN/BLUE SMLV56RGB1W1(5/6/7)
チップＬＥＤ
MASTER B 03
LD401 ZD114500 LED (CHIP) RED/GREEN/BLUE SMLV56RGB1W1(5/6/7)
チップＬＥＤ
TOUCH AND TURN 03
R301 RD354470 CARBON RESISTOR (CHIP) 47.0 63M J RECT.
チップ抵抗
R302 RD354470 CARBON RESISTOR (CHIP) 47.0 63M J RECT.
チップ抵抗
R303 RD355100 CARBON RESISTOR (CHIP) 100.0 63M J RECT.
チップ抵抗
R304 RD355100 CARBON RESISTOR (CHIP) 100.0 63M J RECT.
チップ抵抗
R305 RD356470 CARBON RESISTOR (CHIP) 4.7K 63M J RECT.
チップ抵抗
R306 RD354470 CARBON RESISTOR (CHIP) 47.0 63M J RECT.
チップ抵抗
REF NO.
PART NO.
DESCRIPTION
部品名
REMARKS
QTY RANK
*
: New Parts RANK: Japan only
ENC/PN2/PNL/PNR
