Yamaha QL5 Service Manual

89
QL5/QL1
R734 WA02590R METAL FILM RESISTOR (CHIP) 2.7K 1/10 D RECT.
チップ金皮抵抗
01
R735 WA44950R METAL FILM RESISTOR (CHIP) 8.2K 1/10 D RECT.
チップ金皮抵抗
01
R736 WA44950R METAL FILM RESISTOR (CHIP) 8.2K 1/10 D RECT.
チップ金皮抵抗
01
R737 RD258100 CARBON RESISTOR (CHIP) 100.0K 0.1 J RECT.
チップ抵抗
R738 WA02620R METAL FILM RESISTOR (CHIP) 4.7K 1/10 D RECT.
チップ金皮抵抗
01
R739 WB83030R METAL FILM RESISTOR (CHIP) 33.0K 1/10 D RECT.
チップ金皮抵抗
01
R740 RD255100 CARBON RESISTOR (CHIP) 100.0 0.1 J RECT.
チップ抵抗
R741 RD258100 CARBON RESISTOR (CHIP) 100.0K 0.1 J RECT.
チップ抵抗
R742 WA02720R METAL FILM RESISTOR (CHIP) 16.0K 1/10 D RECT.
チップ金皮抵抗
01
R743 WA02540R METAL FILM RESISTOR (CHIP) 1.8K 1/10 D RECT.
チップ金皮抵抗
01
R744 WA02570R METAL FILM RESISTOR (CHIP) 2.2K 1/10 D RECT.
チップ金皮抵抗
01
R745 WA02570R METAL FILM RESISTOR (CHIP) 2.2K 1/10 D RECT.
チップ金皮抵抗
01
R746 RD255220 CARBON RESISTOR (CHIP) 220.0 0.1 J RECT.
チップ抵抗
R747 RD255220 CARBON RESISTOR (CHIP) 220.0 0.1 J RECT.
チップ抵抗
R748 WA02670R METAL FILM RESISTOR (CHIP) 10.0K 1/10 D RECT.
チップ金皮抵抗
01
R749 RD255100 CARBON RESISTOR (CHIP) 100.0 0.1 J RECT.
チップ抵抗
-754 RD255100 CARBON RESISTOR (CHIP) 100.0 0.1 J RECT.
チップ抵抗
R755 RD257100 CARBON RESISTOR (CHIP) 10.0K 0.1 J RECT.
チップ抵抗
R756 RD256470 CARBON RESISTOR (CHIP) 4.7K 0.1 J RECT.
チップ抵抗
R757 RD256470 CARBON RESISTOR (CHIP) 4.7K 0.1 J RECT.
チップ抵抗
R758 HF757390 CARBON RESISTOR 39.0K 1/4 J AX TP
カーボン抵抗
01
R759 HF757390 CARBON RESISTOR 39.0K 1/4 J AX TP
カーボン抵抗
01
R801
VP44100R METAL FILM RESISTOR 6.8K 1/4 F AX26
金属被膜抵抗
01
R802 VP44100R METAL FILM RESISTOR 6.8K 1/4 F AX26
金属被膜抵抗
01
R803 RD258100 CARBON RESISTOR (CHIP) 100.0K 0.1 J RECT.
チップ抵抗
R804 WZ158100
FLAME PROOF CARBON RESISTOR 390.0 1/4 J VTP
不燃化カーボン抵抗
01
R805 RD15739R CARBON RESISTOR (CHIP) 39.0K 1/4 J TP
チップ抵抗
01
R806 RD257220 CARBON RESISTOR (CHIP) 22.0K 0.1 J RECT.
チップ抵抗
R807 RD257100 CARBON RESISTOR (CHIP) 10.0K 0.1 J RECT.
チップ抵抗
R808 VP439000 METAL FILM RESISTOR 1.0K 1/4 F AX26
金属被膜抵抗
R809 VP437200 METAL FILM RESISTOR 180.0 1/4 F AX26
金属被膜抵抗
01
R810 VP441200 METAL FILM RESISTOR 8.2K 1/4 F AX26
金属被膜抵抗
01
R811 VP441200 METAL FILM RESISTOR 8.2K 1/4 F AX26
金属被膜抵抗
01
R812 VP442401 METAL FILM RESISTOR 27.0K 1/4 F AX26
金属被膜抵抗
01
R813 RD256470 CARBON RESISTOR (CHIP) 4.7K 0.1 J RECT.
チップ抵抗
R814 RD254100 CARBON RESISTOR (CHIP) 10.0 0.1 J RECT.
チップ抵抗
R815 RD254100 CARBON RESISTOR (CHIP) 10.0 0.1 J RECT.
チップ抵抗
R816 WA02800R METAL FILM RESISTOR (CHIP) 47.0K 1/10 D RECT.
チップ金皮抵抗
01
R817 WA02800R METAL FILM RESISTOR (CHIP) 47.0K 1/10 D RECT.
チップ金皮抵抗
01
R818 RD254100 CARBON RESISTOR (CHIP) 10.0 0.1 J RECT.
チップ抵抗
R819 RD254100 CARBON RESISTOR (CHIP) 10.0 0.1 J RECT.
チップ抵抗
R820 WA02570R METAL FILM RESISTOR (CHIP) 2.2K 1/10 D RECT.
チップ金皮抵抗
01
R821 WA02570R METAL FILM RESISTOR (CHIP) 2.2K 1/10 D RECT.
チップ金皮抵抗
01
R823 ZF404900 METAL FILM RESISTOR (CHIP) 82.0 1/10 D KAKUTE
チップ金皮抵抗
01
R824 WE676900 METAL FILM RESISTOR (CHIP) 1.5K 1/10 D RECT.
チップ金皮抵抗
01
R825 WA44950R METAL FILM RESISTOR (CHIP) 8.2K 1/10 D RECT.
チップ金皮抵抗
01
R826 WA44950R METAL FILM RESISTOR (CHIP) 8.2K 1/10 D RECT.
チップ金皮抵抗
01
R827
WA02660R METAL FILM RESISTOR (CHIP) 6.8K 1/10 D RECT.
チップ金皮抵抗
01
R828 WA02660R METAL FILM RESISTOR (CHIP) 6.8K 1/10 D RECT.
チップ金皮抵抗
01
R830 RD256470 CARBON RESISTOR (CHIP) 4.7K 0.1 J RECT.
チップ抵抗
R831 WA02670R METAL FILM RESISTOR (CHIP) 10.0K 1/10 D RECT.
チップ金皮抵抗
01
R832 WA02670R METAL FILM RESISTOR (CHIP) 10.0K 1/10 D RECT.
チップ金皮抵抗
01
R833 RD25439R CARBON RESISTOR (CHIP) 39.0 0.1 J RECT.
チップ抵抗
01
R834 WA02590R METAL FILM RESISTOR (CHIP) 2.7K 1/10 D RECT.
チップ金皮抵抗
01
R835 WA44950R METAL FILM RESISTOR (CHIP) 8.2K 1/10 D RECT.
チップ金皮抵抗
01
R836 WA44950R METAL FILM RESISTOR (CHIP) 8.2K 1/10 D RECT.
チップ金皮抵抗
01
R837 RD258100 CARBON RESISTOR (CHIP) 100.0K 0.1 J RECT.
チップ抵抗
R838 WA02620R METAL FILM RESISTOR (CHIP) 4.7K 1/10 D RECT.
チップ金皮抵抗
01
R839 WB83030R METAL FILM RESISTOR (CHIP) 33.0K 1/10 D RECT.
チップ金皮抵抗
01
R840 RD255100 CARBON RESISTOR (CHIP) 100.0 0.1 J RECT.
チップ抵抗
R841 RD258100 CARBON RESISTOR (CHIP) 100.0K 0.1 J RECT.
チップ抵抗
R842 WA02720R METAL FILM RESISTOR (CHIP) 16.0K 1/10 D RECT.
チップ金皮抵抗
01
R843 WA02540R METAL FILM RESISTOR (CHIP) 1.8K 1/10 D RECT.
チップ金皮抵抗
01
R844 WA02570R METAL FILM RESISTOR (CHIP) 2.2K 1/10 D RECT.
チップ金皮抵抗
01
R845 WA02570R METAL FILM RESISTOR (CHIP) 2.2K 1/10 D RECT.
チップ金皮抵抗
01
R846 RD255220 CARBON RESISTOR (CHIP) 220.0 0.1 J RECT.
チップ抵抗
R847 RD255220 CARBON RESISTOR (CHIP) 220.0 0.1 J RECT.
チップ抵抗
R848 WA02670R METAL FILM RESISTOR (CHIP) 10.0K 1/10 D RECT.
チップ金皮抵抗
01
R855 RD257100 CARBON RESISTOR (CHIP) 10.0K 0.1 J RECT.
チップ抵抗
R856 RD256470 CARBON RESISTOR (CHIP) 4.7K 0.1 J RECT.
チップ抵抗
REF NO.
PART NO.
DESCRIPTION
部品名
REMARKS
QTY RANK
*
: New Parts RANK: Japan only
HAAD

Yamaha QL5 Specifications

General

DJ mixer	-
Product color	Black
Video capability	No
Channels quantity	72 channels
Supported sample rates	44.1, 48 kHz
Digital sound processing	- bit
Phantom power	48 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	200 W
Total Harmonic Distortion (THD)	0.05 %

Weight and Dimensions

Depth	563 mm
Width	828 mm
Height	272 mm
Weight	21800 g
