CPUQL Circuit Board
Component side
（部品側）
2NA-ZG33520
1
not installed
not installed
not installed not installed not installed
2
3
5
20
to LCDC-CN151(Pin 5–6)
to LCD UNIT-CN1(Pin 5–20)
r-JUIJVN#BUUFSZ（リチウム電池）
Battery VN103500
WR846000 (Battery holder for VN103500)
Notice for back-up battery removal. Push the battery
as shown in figure, then the battery will pop up.
Druk de batterij naar beneden zoals aangeven in de
tekening, de batterij springt dan naar voren.
Battery
Battery holder
