Periodic maintenance and adjustment
110
10. Replace the blown fuse with one of the
proper amperage.
RS90P / RS90PLT
1. Negative battery lead
1. Spare fuse
2. Fuel injection system fuse
3. Main fuse
4. EPS fuse
1
1
2
3
4
1. Fuse box
2. “IGN” (ignition) fuse
3. “FAN” (radiator fan) fuse
4. “S/H” (helmet shield heater jack) fuse
5. “HEAD” (headlight) fuse
6. “SIG” (signaling system) fuse
7. “DC” (auxiliary DC jack) fuse
8. Spare fuse
8
1
276543
