Yamaha TSX-130 Owner's Manual

LISTENING TO DAB STATIONS
15 En
Before tuning into DAB stations, an initial scan must be
performed.
When you select the DAB as the source for the first time,
the initial scan is performed automatically.
y
You can also perform the initial scan manually by INIT SCAN
(☞ P. 18). To select INIT SCAN, press FUNCTION → MENU
S/T → Center when the source is set to DAB.
1 Turn on DAB.
y
Pressing the DAB/FM button switches the DAB mode to the
FM mode, or vice versa.
2 The initial scan starts automatically.
While the scan is in progress, “Scanning” and the
> mark appear on the front panel display.
When scanning is complete, “Completed” and the
number of receivable DAB stations appear on the
front panel display.
1 Turn on DAB.
2 Select a DAB station.
Some stations have sub (secondary) stations. The
secondary indicator lights up when a secondary audio
station is selected.
y
You can change the order of DAB stations by STATION
ORDER (☞ P. 18). To select STATION ORDER, press
FUNCTION → MENU S/T → Center when the source
is set to DAB.
When the unit cannot receive the signal from the selected
station, “Off Air” is displayed on the front panel display.
Preparing for DAB reception Tuning DAB stations
Note
Secondary indicator

Yamaha TSX-130 Specifications

General

Impedance	6 Ω
RMS rated power	30 W
Supported radio bands	FM
Preset stations quantity	30
Type	Home audio mini system
Product color	Black
Optical disc player	Yes
Number of optical discs	1 discs
Dimensions (WxDxH)	350 x 120 x 240 mm
Media types supported	MP3, WMA
Disc types supported	CD, CD-R, CD-RW
USB 2.0 ports quantity	1

Weight and Dimensions

Weight	4000 g
