5-41
CHAS
HANDLEBAR
Extent of removal: 1 Throttle disassembly
Extent of removal Order Part name Q’ty Remarks
THROTTLE DISASSEMBLY
1 Grip cap (lower) 1
2 Grip cap (upper) 1
3 Grip assembly 1
4 Grip (right) 1 Refer to “REMOVAL POINTS”.
5 Tube guide 1
1
EC5B8000
THROTTLE DISASSEMBLY
4 Nm (0.4 m•kg, 2.9 ft•lb)
