Yamaha YZ250(N)/LC User Manual

5-48
CHAS
STEERING
EC563000
REMOVAL POINTS
EC563202
Ring nut
1. Remove:
9Ring nut 1
Use the ring nut wrench 2.
w
Support the steering shaft so that it may
not fall down.
EC563300
Bearing (lower)
1. Remove:
9Bearing (lower) 1
Use the floor chisel 2.
cC
Take care not to damage the steering shaft
thread.
EC563400
Ball race
1. Remove:
9Ball race 1
Remove the ball race using long rod 2
and the hammer.
EC564000
INSPECTION
EC564200
Steering shaft
1. Inspect:
9Steering shaft 1
Bend/Damage → Replace.
Ring nut wrench:
YU-33975/90890-01403
5MW-9-30-5C 7/6/00 10:45 AM Page 18
