Yamato DP23C User Manual

8
Before Using this unit
Requirements for Installation
12. List of vacuum pump plumbing
Item
Modle of
vaccum oven
Maker
Modle of
Suitable
vacuum pump
Nipple for
suction
port of
vacuum pump
Necessary plumbing part
PD(PX)52
*1
Dia.18mm Vacuum hose:I.D.15mm 1pc
DP23C/33C
(Nipple of
vacuum oven
for connecting
vacuum hose:
Dia.18mm)
Yamato
PD(PX)102
PD(PX)136
*1
Dia.30mm
Vacuum hose: I.D.15mm 1pc
Vacuum hose: I.D.25mm 1pc
Reducer,AorC(Dia.18mm/
Dia.30mm) 1pc
Yamato
PD(PX)136
*1
PD(PX)201
*1
Dia.30mm
Vacuum hose: I.D.25mm 1pc
Rubber tube adapter: 1pc
Clamp(NW25/30): 1pc
Center ring(NW25): 1pc
上海西马特 2ZX-4B,220V
NW25
flange
Flexible hose: 1pc
Clamp(NW25/30): 1pc
Center ring(NW25): 1pc
DP43C/63C
(Flange of
vacuum oven
for connecting
vacuum hose:
NW25)
Mitsubishi
VP-SW
-A200(S)
-A310(S)
NW25 flange
Flexible hose: 1pc
Clamp(NW25/30): 2pc
Center ring(NW25): 2pc
