Yamato DP23C - Specification

38
Specification
DP23C DP33C DP43C DP63C
Method Pressure relief and wall heating
Temperature control
range
Room temp +5℃. to 240℃ Room temp +5℃. to 200℃
Temperature
adjustment
accuracy
±1.5℃ (Middle of furnace, Set temp.:
240℃,)
±1℃ (Middle of furnace, Set temp.:
200℃,)
Room temp. to 240℃ Room temp. to 200℃
Temperature rise
time
Approx. 60min. Approx. 90min. Approx. 80min. Approx. 120min.
(240 to 50℃) (200 to 50℃)
 Temperature fall
time
Approx. 250min. Approx. 320min. Approx.550min. Approx. 600min.
SUS pipe heater
Heater
0.68kw 1.05kw 2.25kw 3.15 kw
Controller type VS4
Temperature control
system
PID control for heater output by microcomputer
Setting system Digital setting by menu key and up/down keys
Operation mode Fixed temperature, Quick auto stop, Auto stop, Auto start, Program operation
Sensor K-thermocouple
Additional functions Lock function, Auto recovering after power failure, Calibration offset
Self-diagnostic
functions
Failure of Sensor, heater, SSR, memory, internal communication,
temperature inputting circuit, automatic overheating prevention device,
overheating prevention device, measurement temperature
Safety device Overheating prevention device
External dimensions
(W×D×H mm)
200×250×200 300×300×300 450×450×450 600×600×600
Internal dimensions
(W×D×H mm)
400×410×682 510×460×782 670×669×1500 820×819×1650
Capacity 10L 27 L 91 L 216L
Door Single door, silicon packing
220V AC single phase
Power supply
(50Hz)
3.1A 4.8A 10.3A 14.3A
Weight Approx. 43Kg Approx. 69Kg Approx. 190Kg Approx. 290Kg
Shelf (withstand load: 15kg/one shelf)
×2
Accessories
Instruction manual
 The performance under the power supply condition of AC 220V are shown here.
 The usable ambient temperature of the unit is from 5℃ to 35℃.
 The temperature fall time here shows the reference value.
