Yamato DP23C User Manual

6
Before Using this unit
Requirements for Installation
4. Do not modify 5. Installation on horizontal surface
• Modification of this unit is strictly
prohibited. This could cause a failure.
• Set this unit to the flattest place. Setting
this unit on rough or slope place could
cause the vibration or noise, or cause the
unexpectible trouble or malfunction.
T0305.02 .03 -05
Hazard
High Temperature
Do NOT touch.
burns.
Contact ma y result in sever
WARNING
Explosion Hazard
substances inside.
with flammable or e xplosive
Do NOT operate cham ber
T0305.02.03-08T0305.02.03-08
DANGER
MinMin
Intake Speed Exhaust Speed
Max
Max
DP43C
Vacuum Drying Oven
T0305.02.03-05
Hazard
High Temperature
Do NOT touch.
burns.
Contact ma y result in sever
WARNING
Explosion Hazard
substances inside.
with flammable or e xplosive
Do NOT operate cham ber
T0305.02.03-08T0305.02.03-08
DANGER
MinMin
Int ake Speed Exhaust Speed
Max
Max
DP43C
Vacuum Drying Oven
CAUTION!
6. Do not make an overload 7. Do not set samples in close formation
• The withstand load of shelf is 15kg
（uniform load）Set the samples apart
each other.
• The temperature in furnace cannot be
controlled if too much samples are set
there. Make sure to use the shelf and
set samples apart each other so as to
make the free space of 30% or more to
the furnace to acquire accuracy of
temperature.
Make the free space of 30% or more
Do not modify
Samples
Shelf
15Kg
To the flattest place
