YAMAZAKI MAZAK INTEGREX i Series User Manual

4 MACHINING PROGRAM
4-78
B. Using upper turret and HD1 for milling, lower turret HD2 is using for turning
1. Sample program
G109L1
M901
M200
M212
G0G90G94G55G97
G40G49G80G67G69
G91G28X0
G28Z0
G28Y0
G28B0
M950
T001T002M06
G91G28X0
G28Y0
G28Z0
M108
G90G53B0
M107
G97M03S3000
G10.9X0
M51
M951
M210M107
G90G43G00X0.Y-7.H1P0
G82Z-1.R3.F115.
Y0.
Y-7.
G80
Z50.0
G40
M05
M202
M952
M09
G91G28X0
G28Z0
G28Y0
G28B0
M30
Machining
(Upper turret: HD1- Milling, Lower turret: HD2- Turning (1/2))
jiku
Preparation motion for machining
 G109L1: Upper turret selection
 M901: HD1 spindle selection
 M200: C-axis connect/Milling mode select
 M212: C-axis unclamping
 G94: Feed per minute
 G97: Constant surface speed control OFF
 T001M06: Tool change (TNo.01)
 B-axis positioning
 M107: B-axis clamping
 G97S3000: Rotation speed 3000 min
-1
 M03: Milling spindle forward rotation
 G10.9X0: Radius data input mode
 M51: Milling spindle-through coolant ON
Machining motion
End motion for machining
 M05: Stop of milling spindle rotation
 M202: C-axis disconnect/turning mode
 M09: All coolants OFF
 Each axis positioning to zero return
 M30: Reset and rewind
