MACHINING PROGRAM 4
4-15
4-4 Machining Motion
This section explains “Machining motion”.
This section describes “program composition”, “parameter setting” and “sample program” for
each machining method.
4-4-1 Turning program
This section explains turning operation programs.
1. Turn–drilling operation
Turn-drilling needs to use a G97 (Constant surface speed control OFF) as it cuts at the spindle
center.
A. Sample program
G109L1
M901
M202
G00G18G90G95G54G97
G40G49G80G67G69
G91G28X0
G28Z0
G28Y0
T001.1T002.15M06
G91G28X0
G28Y0
G28Z0
M108
G90G53B0.0
M107
G97S2000M204
G10.9X1
M08
G90G43G0X0.0Y0Z5.0 H1P1
M250
G274R1.0
G274X0Z-50.0P0Q15.0F0.2
G0X300.0Z50.0
G80
M205
M09
G91G28X0
G28Z0
G28Y0
M30
Preparation Motion for machining
• G109L1: Upper turret selection
• M901: HD1 spindle selection
• M202: C-axis disconnect / turning mode
• G95: Feed per revolution
• G97: Constant surface speed control OFF
• T001.1M6: Tool change (TNo.01.A)
• B-axis positioning
• M107: B-axis clamping
• G97S2000: Rotation speed 2000 min
-1
• M204: Turning spindle1 backward rotation
• G10.9X1: Diameter data input mode
• M08: Flood coolant ON.
End motion
• M205: Turning spindle1 Rotation stop
• M09: All coolants OFF
• Each axis positioning to zero return
• M30: Reset and rewind
Machining motion
• G43H**P1: Tool length offset
• M250: Spindle speed attainment check
• G274: Longitudinal cut-off cycle
• G80: Fixed cycle OFF
(Turning operation – Turn drilling operation)
Serial No. 294060
Copyright (c) 2013 YAMAZAKI MAZAK CORPORATION. All rights reserved.
