2-1 Controlled Axis Information
This section describes Composition of controlled axes, machine specification, machine stroke,
input limitation, rotating speed, rapid feed rate and cutting feed rate.
2-1-1 Composition of controlled axes
This section indicates composition of controlled axes.
1. INTEGREX i/i-S/i-ST/e-H/e-H-S/e-H-ST
The axes of coordinates used for machine control are defined as follows:
Refers to the vertical motion of the upper turret.
“+” (plus) indicates the upward direction (away from the spindle center);
“–” (minus) indicates the downward direction (towards the spindle center).
Refers to the transverse motion of the upper turret.
“+” (plus) indicates the rightward direction (away from the chuck);
“–” (minus) indicates the leftward direction (towards the chuck).
Refers to the rotation of the work spindle.
“+” (plus) indicates the right-hand rotation (CW);
“–” (minus) indicates the left-hand rotation (CCW).
Refers to the longitudinal motion of the upper turret.
“+” (plus) indicates the forward direction (to the front);
“–” (minus) indicates the backward direction (to the rear).
Refers to the rotation of the secondary spindle.
“+” (plus) indicates the left-hand rotation (CCW);
“–” (minus) indicates the right-hand rotation (CW).
Refers to the transverse motion of the secondary headstock.
“+” (plus) indicates the rightward direction;
“–” (minus) indicates the leftward direction.
Refers to the vertical motion of the lower turret.
“+” (plus) indicates the downward direction (away from the spindle center);
“–” (minus) indicates the upward direction (towards the spindle center).
Refers to the transverse motion of the lower turret.
“+” (plus) indicates the rightward direction;
“–” (minus) indicates the leftward direction.
