C. Combination of tool tip point control (G43.4, G43.5) and other function
The table below shows the modes in which tool tip point control (G43.4, G43.5) is selectable and
the selectable code in tool tip point control.
: Selectable, - : Not selectable
G43.4 (G43.5)
commanded in
leftward code mode
Leftward code
commanded in G43.4
(G43.5) mode.
Circular interpolation (CW)
Circular interpolation (CCW)
High-speed machining mode ON
High-speed machining mode OFF
Cylindrical Interpolation
Polar coordinate interpolation ON
Polar coordinate interpolation OFF
Return to Second Reference Point
Thread cutting (straight, taper)
Nose radius/Tool radius compensation OFF
Nose radius/Tool radius compensation (left)
Tool radius compensation for five-axis machining
(left)
Nose radius/Tool radius compensation (right)
Tool radius compensation for five-axis machining
(right)
Tool length offset in tool-axis direction
Tool tip point control (Type 1) ON
Tool tip point control (Type 2) ON
Coordinate system setting/Spindle speed range
setting
Selection of machine coordinate system
Tool-axis direction control
Selection of workpiece coordinate system 1
Workpiece setup error correction
Selection of workpiece coordinate system 2
Selection of workpiece coordinate system 3
Selection of workpiece coordinate system 4
Selection of workpiece coordinate system 5
Selection of workpiece coordinate system 6
Selection of additional workpiece coordinate
systems
High-accuracy mode (Geometry compensation)
