COOLING SYSTEM
TNV IDI Service Manual
8-9
Engine Coolant Pump
Figure 8-11
9. Reinstall the V-belt. Tighten the V-belt to the
proper tension. See Check and Adjust Cooling
Fan V-Belt on page 5-15.
10. Reinstall and tighten the drain plug or close the
drain cock in the radiator. Reinstall and tighten
the engine block drain plug or reconnect the
coolant hose at the oil cooler.
11. Fill radiator and engine with engine coolant.
See Drain, Flush and Refill Cooling System with
New Coolant on page 5-21.
• Only use the engine coolant specified. Other
engine coolants may affect warranty
coverage, cause an internal buildup of rust
and scale and / or shorten engine life.
• Prevent dirt and debris from contaminating
the engine coolant. Carefully clean the
radiator cap and the surrounding area before
you remove the cap.
• NEVER mix different types of engine
coolants. This may adversely affect the
properties of the engine coolant.
