TROUBLESHOOTING
13-6
TNV IDI Service Manual
Quick Reference Table For Troubleshooting
Measured Value and Troubleshooting
When the measured compression pressure is below the limit value, inspect each part by referring to the
table below.
QUICK REFERENCE TABLE
FOR TROUBLESHOOTING
The following table summarizes the general trouble
symptoms and their causes. If any trouble symptom
occurs, take corrective action before it becomes a
serious problem so as not to shorten the engine
service life.
No. Item Cause Corrective Action
1 Air Cleaner Element
Clogged element Clean the element.
Broken element
Replace the element.
Defect at element seal portion
2 Valve Clearance Excessive or no clearance Adjust the valve clearance.
3 Valve Timing Incorrect valve clearance Adjust the valve clearance.
4 Cylinder Head Gasket Gas leak from gasket
Replace the gasket.
Retighten the cylinder head bolts to the specified
torque.
5
Intake / Exhaust Valve Sticking valve Replace the intake / exhaust valve.
Valve Seat
Gas leak due to worn valve seat
or foreign matter trapped in
valve
Lap the valve seat.
6
Piston
Gas leak due to scratching or
wear
Perform honing and use an oversized part.Piston Ring
Cylinder
