Yanmar 2TNV70 - Intake; Exhaust Valve and Guide; Push Rod; Valve Spring

ENGINE
TNV IDI Service Manual
6-5
Cylinder Head Specifications
Intake / Exhaust Valve and Guide
Push Rod
Valve Spring
Inspection Item Standard Limit
Reference
Page
Intake
Guide Inside Diameter
0.2362 - 0.2367 in.
(6.000 - 6.012 mm)
0.2394 in.
(6.08 mm)
See
Inspection of
Valve
Springs on
page 6-26
Valve Stem Outside
Diameter
0.2346 - 0.2352 in.
(5.960 - 5.975 mm)
0.2323 in.
(5.90 mm)
Oil Clearance
0.0010 - 0.0020 in.
(0.025 - 0.052 mm)
0.0063 in.
(0.15 mm)
Valve Stem Bend -
0.0004 in.
(0.010 mm)
Exhaust
Guide Inside Diameter
0.2362 - 0.2367 in.
(6.000 - 6.012 mm)
0.2394 in.
(6.08 mm)
Valve Stem Outside
Diameter
0.2341 - 0.2346 in.
(5.945 - 5.960 mm)
0.2323 in.
(5.90 mm)
Oil Clearance
0.0016 - 0.0026 in.
(0.040 - 0.067 mm)
0.0067 in.
(0.17 mm)
Valve Stem Bend -
0.0004 in.
(0.010 mm)
Valve Guide Projection From Cylinder Head
0.3858 - 0.3937 in.
(9.8 - 10.0 mm)
-
See
Reassembly
of Valve
Guides on
page 6-27
Valve Stem Seal Projection From Cylinder Head
0.429 - 0.441 in.
(10.9 - 11.2 mm)
Valve Guide Installation Method Cold-fitted -
Inspection Item Standard Limit
Reference
Page
Push Rod Bend
Less than 0.0012 in.
(0.03 mm)
0.0012 in.
(0.03 mm)
See Push
Rod Bend on
page 6-23
Inspection Item Standard Limit
Reference
Page
Free Length
1.4882 in.
(37.8 mm)
-
See
Inspection of
Valve
Springs on
page 6-26
Squareness -
0.0512 in.
(1.3 mm)
