Accessory power output
The harness attached to the panel has a terminal where the signal that is synchronized to
the panel power supply can be taken off. (Figure 13) ( Refer to the Wiring Diagrams on
page 94.)
The maximum current of this output terminal is 3 A. Do not use a current higher than 3 A.
For the content of the output terminal, refer to the Wiring Diagrams on page 94.
Figure 3
Figure 13
043801-00E00
F1A - 3 AMP Fuse
Buzzer
ACC Output
