Yaohua Weighing System XK3190-A23p User Manual

X K 3 1 9 0 –A23p
(21)
2 + or - Symbol bit
3~8
Weighing data（display
value）
front is high digit and low in the post
9 Decimal position
From right to left（0～4）
10 XOR checksum Higher four digits
11 XOR checksum Lower four digits
12 03(X0FF) End
Note: The confirmation of higher 4 digits and lower 4 digits XOR
checksum
XOR checksum operated in 16 hex byte way from byte 2 to byte 9. The high
4 and low 4 bits of checking result was conversion and transmit in ASCII code,
conversion method are as follows:
If less than, or equal to 9, then add 30h, will send a number of ASCII code,
for example: XOR checksum high 4 to 6, after adding 30h, 36h is ASCII code for
the 6 to send;
If higher than 9, then add 37h, will send a letter ASCII code, for example:
XOR checksum high 4 bits of B, plus 37h, the ASCII code for the 42h that is
sending B

Continuous communication format 2
There are 9 bytes in each frame data, and detail format please
check the diagram as below.
The X byte Content and Note
1 = Start
2~8
Weighing data （including
decimal point）
lower position in front and high
position in behind
9 0 or- symbol position
For example the current weight is -1.00，so the sending data is：
＝00.1000－＝00.1000－＝00.1000－＝00.1000－

Yaohua Weighing System XK3190-A23p Specifications

General

Model	XK3190-A23p
Category	Accessories
Display Type	LCD
Display Digits	6
Accuracy Class	III
Max. Division	3000
Excitation Voltage	5V DC
Interface	RS232
Load Cell Connection	Up to 4 load cells
Display	LCD with backlight
Power Supply	AC/DC
Operating Temperature	0°C to 40°C
Humidity	< 85% RH
Weight Units	kg, lb

Summary

Chapter 1 Technical Parameter

Chapter 2 Installation

Front and Back Panel Functions

Describes the layout and controls on the front and back panels of the weighing indicator.

Load Cell Connection

Explains how to connect the load cell to the weighing indicator using a 5-pin plug.

Communication Interface

Details the definitions for RS232 and scoreboard current loop communication interfaces.

Chapter 3 Operation Instruction

Basic Operations and Setup

Covers indicator startup, battery usage, button functions, and zero/tare operations.

Data Entry and Calculation Features

Details unit price management, accumulation, and various pricing calculation methods.

Settings and Specialized Functions

Configuration for date, time, backlight, alarms, and weighing unit selection.

Chapter 4 Save, Inquire and Clear

Data Saving Function

Describes how the indicator saves records automatically during accumulation.

Data Inquiry Function

How to search and view stored accumulation records by S/N or date.

Data Clearing Functions

Procedures for clearing all records, a group, or current details.

Chapter 5 Printing Function

Printing Operations and Modes

Covers various printing functionalities like auto print, manual print, and specific transaction prints.

Print Configuration and Formats

Details print settings, content selection, and provides examples of print formats.

Chapter 6 Communication Function

Communication Setup and Protocols

Covers wiring, parameter settings, communication protocols, and display modes.

Chapter 7 Information Indication

Error 03: Overload Alarming

Indicates overload alarming and suggests removing load.

Error 05: AD Part Fault

Describes AD part faults and recommends checking sensor or factory repair.

Error 08: Parameter Input Error

Signifies incorrect parameter input and requests re-entry.

Error 09: Accumulate/Print Request Issue

Indicates failure to meet accumulate count or print request requirements.

Error 10: Unit Weight Locked

Unit weight too small, stopping count function and locking weight.

Chapter 8 Maintenance and Attention

Environmental and Placement Guidelines

Advises on suitable locations, avoiding dust, vibration, moisture, and direct sunlight.

Safety and Protection Measures

Details electrical safety, grounding, static protection, power connections, and lightning protection.

Maintenance, Battery, and Warranty

Covers cleaning, battery care, interface repair, company advice, and warranty terms.
