Yaohua Weighing System XK3190-A23p User Manual

X K 3 1 9 0 –A23p
(22)
Continuous communication format 2：
There are 9 bytes in each data of the frame, for more details please check the
diagram below.
The X byte Contents and Notes
1 = start
2 0 or - symbol position
3~9
Weighing data （including
decimal point）
high position in front and low
position at behind
For example the current weight is 3.000，so the sending data is：
＝0003.000＝0003.000＝0003.000＝0003.000
For example the current weight is -1.00，so the sending data is：
＝－0001.00＝－0001.00＝－0001.00＝－0001.00
Continuous communication format 4：
There are 27 bytes in each data of the frame, for more details please check the
diagram below.
The X byte Content and Note
1 = start
2 0 or - symbol position
3～9
Weighing data
high position in front and low
position at behind
10、11
Weighing unit kg or lb or pc
12
；
separator
13～19
unit price
high position in front and low
position at behind
20
；
separator
21～27
amount
high position in front and low
position at behind
For example the current unit is kg，weight is 2.000，unit price1.00，amount is2.00，
so the sending data is：

Yaohua Weighing System XK3190-A23p Specifications

General

Model	XK3190-A23p
Category	Accessories
Display Type	LCD
Display Digits	6
Accuracy Class	III
Max. Division	3000
Excitation Voltage	5V DC
Interface	RS232
Load Cell Connection	Up to 4 load cells
Display	LCD with backlight
Power Supply	AC/DC
Operating Temperature	0°C to 40°C
Humidity	< 85% RH
Weight Units	kg, lb
