X K 3 1 9 0 –A23p
(23)
＝0002.000kg;0001.00;0002.00＝0002.000kg;0001.00;0002.00……
For example the current display is quantity, and the quantity is 20,unit price is
1.00,amount is 20.00 , so the sending data is :
＝00000020pc;0001.00;0020.00＝00000020pc;0001.00;0020.00……
Three windows large screen mode：
There are 24 bytes in each of the frame，please check the detailed format in the
below diagram .
The x
byte
Content and note
1 S(53H) start
2 T(54H) start
3～8
the first window displays
data
9 0x0a Change line symbol (\n)
10～15
the second window
displays data
16 0x0a Change line symbol (\n)
17～22
the third window displays
data
23 0x31 Fixed
24 0x0d Enter symbol(\r)
Send data synchronization with the indicator’s display, the screen can be used as
an extension one.
For more detailed data format specification please check YH three large-screen
window user’s manual..
The command mode：
Indicator sending corresponding data according to the commands of the host
computer, indicator will send a frame of data each time when host computer sending
a command.
Command list （indicator communication address take 01 as example）：
