Yardistry YM12842 - Page 19

19 support@yardistrystructures.com
#8 x 3” Wood Screws
Connects Right and Left Door Posts
to Front Base
#8 x 3” Wood Screws
Connects Right and Left Door Posts
to FB Wall Panel and Front Base to
FB Wall Panel
Top
Bottom
(1147) FB Panel
F2.4
F2.5
(1111) Left
Door Post
B: In the grooves of each post slide one
(1147) FB Panel down so they rest tight to
the top of the (1119) Front Base. (F2.4)
C: Place one (1111) Left Door Post and
one (1112) Right Door Post tight to each
(1147) FB Panel then attach to (1119)
Front Base with two #8 x 3” Wood Screws
per post. (F2.4 and F2.5)
(1112) Right
Door Post
#8 x 3” Wood Screw
Tight
Hardware
4 x #8 x 3” Wood Screw
Wood Parts
1 x (1111) Left Door Post
1 x (1112) Right Door Post
2 x (1147) FB Panel
(1109)
Right
Post
(1108)
Left Post
(1119) Front Base
(1147) FB
Panel
(1147) FB
Panel
(1119) Front Base
Post
Door
Post
Step 2: Front Wall Assembly
Part 2
