#8 x 3” Wood Screws
Connects Right and Left Door Posts
to FB Wall Panel and Front Base to
FB Wall Panel
#8 x 3” Wood Screws
Connects Right and Left Door Posts
to FB Wall Panel and Front Base to
FB Wall Panel
#8 x 3” Wood Screws
Connects Right and Left Door Posts
to FB Wall Panel and Front Base to
FB Wall Panel
F2.7
F2.8
D: Attach (1111) Left Door Post and (1112) Right Door Post to (1147) FB Panel with one #8 x 3” Wood Screw per
post. (F2.6 and F2.7)
E: Attach (1119) Front Base to (1147) FB Panels with three #8 x 3” Wood Screws per panel. (F2.6 and F2.8)
F2.6
Hardware
8 x #8 x 3” Wood Screw
(1147)
FB Panel
(1111) Left
Door Post
(1112) Right
Door Post
(1119) Front Base
(1147) FB
Panel
(1147) FB
Panel
(1111) Left
Door Post
(1112) Right
Door Post
(1119) Front Base
(1147) FB
Panel
#8 x 3” Wood Screw
#8 x 3” Wood Screw
(1147) FB
Panel
Step 2: Front Wall Assembly
Part 3
